| PART.No. |
D |
d |
L |
L1 |
H |
W |
B |
PANEL
HOLE SIZE |
| VUH-02-0 |
1/4":6.35 |
5 |
67 |
15.4 |
73 |
58 |
14 |
18.5 |
| VUH-025-0 |
5/16":7.94 |
5 |
68 |
16.8 |
73 |
58 |
15.87 |
18.5 |
| VUH-036-0 |
3/8":9.53 |
5 |
72 |
20.3 |
83 |
68 |
17.46 |
22.5 |
| VUH-04-0 |
1/2":12.7 |
5 |
80 |
22.8 |
83 |
68 |
23 |
22.5 |
|
|
| SIZE |
MAX Cv値 |
| φ6.35 |
0.36 |
| φ7.94 |
0.48 |
| φ9.53 |
0.58 |
| φ12.7 |
0.58 |
|
